Product Details:
Payment & Shipping Terms:
|
| Condition: | 100% New | Application: | Buildings And Projects |
|---|---|---|---|
| Type: | Fixed With Tower Head | Max. Load: | 6 T |
| Jib Length: | 50 M | Tip. Load: | 1.3 T |
| Power supply: | 380V/50Hz Or According To Client's Requirements | Mast section: | 1.6*1.6*2.5m (blcok Type) |
| Electric Box: | Schneider | Power Supply: | 380V/50Hz, 415V/50Hz, 220V/50Hz Or According To Clients Need |
3 Phase Power Tower Crane Hammer-head Tower Kren qtz63(5013) Models
Main Technical Parameters
1) Nominal Lifting Moment: 630KN.m
2) Working Range: 3-50m
3) Max. Lifting Capacity: 6t
4) Independent Standing Height: 40m
5) Attached Standard Height: 150m
6) Lifting Speed: 80/40/8.5 40/20/4.25 m/mim
7) Slewing Speed: 0.6r/min
8) Radius Changing Speed: 40/20m/mim
Specification
| Foundation | fixed or mobile |
| Free height | 40 meters |
| Max. height | 150 meters |
| Max. radius | 50 meters |
| Jib end load | 1.3 t |
| Max. load | 6 T |
| Drum capacity | 400 meters |
| Lifting speed | 80/40/8.5 40/20/4.25m/min |
| Slewing speed | 0.6 r/in |
| Trolley speed | 40/20 m/min |
| Power line voltage | 380V/50Hz (60Hz) |
| Counter weight | Stell-structured frame (without concrete) |
| Mast section | 1.68 x 1.68 x 2.5 m or 1.6*1.6*2.5 m |
Main features
This tower crane, has a horizontal jib frame, a jib-trolley radius-changing mechanism and a hydraulic self-raising mechanism.
It is original in design, reliable in operation and satisfactory in shape.
Equipped with all necessary safety devices, these cranes show a good speed-control capacity, satisfactory operating stability and high work efficiency.
They can be widely used for the construction of high-rise hotels, residential buildings, high-rise industrial buildings, large-span factory buildings and tower-like buildings like tall chimneys.
Applications
It’s used in construction building site, such as Multi commercial housing, High rise building, Skyscraper, and Workshop Material handling etc.
Pictures
