Product Details:
Payment & Shipping Terms:
|
| Condition: | 100% New | Application: | Buildings And Projects |
|---|---|---|---|
| Type: | Fixed Out Climbing | Load: | 6t |
| Jib: | 60m | Tip. Load: | 1.3t |
| Mast section: | 1.6*3m (split Type) | Electric Box Contractor: | Schneider |
| Power Supply: | 380V/50Hz, 415V/50Hz, 220V/50Hz Or According To Clients Need | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service |
TC6013 Topkit Tower Crane 6 ton L46 Mast Section 1.6*3m Split Type In Central Asia
Quick Details
Specification
| Model | QTZ100(6013) Tower Crane | |
| Working Radius (m) | 60 | |
| Max. Load Capacity (T) | 6 | |
| Tip Load (T) | 1.3 | |
| Free standing height (m) | 50 | |
| Max. Height with anchorages (m) | 150 | |
| Mast Section dimension (m) | 1.6×1.6×3, 180×18mm | |
|
Hoisting Mechanism |
Speed (m/min) | 80/40/20 40/20/15 |
| Motor power (kw) | 30/30 | |
|
Slewing Mechanism |
Speed (r/min) | 0.6 |
| Motor power (kw) | 2*3.7 | |
|
Trolleying Mechanism |
Speed (m/min) | 40/20 |
| Motor power (kw) | 3.3/2.2 | |
|
Jacking-up System |
Speed (m/min) | 0.4 |
| Motor power (kw) | 5.5 | |
| Total Power (kw) | 46.2 | |
| Power Supply | 380V/50Hz, 220V/60Hz or others | |
Our Service
------Quality Assurance
Good quality is assured by advanced manufacturing technology. And all products will be checked by our quality-control manager.
------Excellent Package
We provide standard, strong, protective package for our products to prevent it from outer damage.
------Warranty Assurance
For our tower crane, we provide 1 year warranty period and quick replace service.
------The Fastest Reply
Detailed information,specific model and price of products will be provided quickly after receiving inquiry.
Safety devices:
1) Hoist height limit
2) Over speed limit
3)Over load limit
4) Lifting moment limit
5) Slewing angle limit
6) Emergency stop button
7) Obstruction light (tip of jib, tower head)
8) Wind lock device.
Competitive Advantage
1. Focusing on tower crane exporting for 15 years;
2. Manufacturer's representative;
3. Preferential ex-factory price, excellent product quality and good after-sales service are our pursuit;
4. Our tower cranes had exported to more than 20 countries, such as Vietnam, Philippines, Indonesia, India, Sri Lanka, Cambodia, Russia, Kazakhstan, Brazil, Cyprus, Belgium, Madagascar and Algeria etc.
We are dedicated to provide you professional solutions with Aclass Service!
Pictures
More products available: Construction Machinery
Tower Cranes
---- QTZ Topkit/Hammer Head Tower Cranes: Working jib from 30-75m and max.load from 4-25t.
---- PT Topless/Flat Top Tower Cranes: Working jib from 30-80m and max.load from 4-32t.
---D Luffing Tower Crane: Working jib from 25-60m and max.load from 3-25t.
---QD Derrick Crane: load from 3t to 25t for disassemble inner climbing tower cranes.
SC Construction Man and Material Elevator
------ Rack and pinion elevator, special for the lifting work of construction Man and Material, 1000kg to 4000kg capacity, Passenger and Material, up to 200m. .
SS Building Material Lift / Hoist
------ Wire rope lift, special material lifting work in construction site, 1000kg to 2000kg capacity, no passenger, up to 60m.
SJY Scissor Lift
Gantry Crane
Small Jib Crane
