Payment & Shipping Terms:
|Condition:||100% New||Application:||Buildings And Projects|
|Type:||Fixed With Tower Head||Max. Load:||8 T|
|Jib Length:||60 M||Tip. Load:||1.2 T|
|Power supply:||380V/50Hz Or According To Client's Requirements||Mast section:||1.835*1.835*2.5m (blcok Type)|
|Electric Box:||Schneider||Power Supply:||380V/50Hz, 415V/50Hz, 220V/50Hz Or According To Clients Need|
QTZ100 Remote Control Construction Cranes Tower 60 Meter 8T Capacity
Related technical parameters are as following in detail:
|Model||QTZ100(6012) Tower Crane|
|Working Radius (m)||60|
|Max. Load Capacity (T)||8|
|Tip Load (T)||1.2|
|Free standing height (m)||45|
|Max. Height with anchorages (m)||150|
|Mast Section dimension (m)||1.835×1.835×2.5, square steel 135×12mm|
|Speed (m/min)||80/40/8.5 40/20/4.25|
|Motor power (kw)||30/30|
|Motor power (kw)||2*3.7|
|Motor power (kw)||3.3/2.2|
|Motor power (kw)||5.5|
|Total Power (kw)||46.2|
|Power Supply||380V/50Hz, 220V/60Hz or others|
Good quality is assured by advanced manufacturing technology. And all products will be checked by our quality-control manager.
We provide standard, strong, protective package for our products to prevent it from outer damage.
For our tower crane, we provide 1 year warranty period and quick replace service.
------The Fastest Reply
Detailed information,specific model and price of products will be provided quickly after receiving inquiry.
1) Hoist height limit
2) Over speed limit
3)Over load limit
4) Lifting moment limit
5) Slewing angle limit
6) Emergency stop button
7) Obstruction light (tip of jib, tower head)
8) Wind lock device.
1. Focusing on tower crane exporting for 15 years;
2. Manufacturer's representative;
3. Preferential ex-factory price, excellent product quality and good after-sales service are our pursuit;
4. Our tower cranes had exported to more than 20 countries, such as Vietnam, Philippines, Indonesia, India, Sri Lanka, Cambodia, Russia, Kazakhstan, Brazil, Cyprus, Belgium, Madagascar and Algeria etc.
We are dedicated to provide you professional solutions with Aclass Service!
