qtz100 60m Hammer-Head Tower Crane For 150m Building Construction

Product Details

Place of Origin: China

Brand Name: AVITT or others

Certification: CE, ISO, GOST, CU-TR

Model Number: QTZ100(6012) Tower Crane

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $64300-66800 per set

Packaging Details: Naked packing, 6*40’HQ containers.

Delivery Time: 20 days after receiving the deposit or origin LC

Payment Terms: TT, LC

Supply Ability: 20 sets per month

Get Best Price
Product Details
Highlight:
Condition:
100% New
Application:
Buildings And Projects
Type:
Fixed With Tower Head
Max. Load:
8 T
Jib Length:
60 M
Tip. Load:
1.2 T
Power supply:
380V/50Hz Or According To Client's Requirements
Mast section:
1.833*1.833*2.5m (blcok Type)
Electric Box:
Schneider
Power Supply:
380V/50Hz, 415V/50Hz, 220V/50Hz Or According To Clients Need
Condition:
100% New
Application:
Buildings And Projects
Type:
Fixed With Tower Head
Max. Load:
8 T
Jib Length:
60 M
Tip. Load:
1.2 T
Power supply:
380V/50Hz Or According To Client's Requirements
Mast section:
1.833*1.833*2.5m (blcok Type)
Electric Box:
Schneider
Power Supply:
380V/50Hz, 415V/50Hz, 220V/50Hz Or According To Clients Need
Product Description

qtz100 60m Hammer-Head Tower Crane For 150m Building Construction

QTZ100 serial tower crane are designed by HYCM. Their steel are selected from Chinese big steel enterprise. Welding material comes from famous corporations of domestic market.
Related technical parameters are as following in detail:

  1. Lifting capacity: 8ton, Boom length: 60m
  2. Stationary height: 45m, adhered height: 150m.
  3. Standard section: 1833*1833*2500mm, Square steel: 135X12mm
  4. Hoisting speed (2 ratio): 80/40/8.5m/min, (4ratio): 40/20/4.25m/min
  5. Slewing speed: 0.6 r/min
  6. Trolleying speed: 40/20 m/min
  7. Hydraulic-hoisting speed: 0.4
  8. The min descending speed: less than 7 m/min
  9. Ddmitted working temperature : -20 to +40

Specification

Model QTZ100(6012) Tower Crane
Working Radius (m) 60
Max. Load Capacity (T) 8
Tip Load (T) 1.2
Free standing height (m) 45
Max. Height with anchorages (m) 150
Mast Section dimension (m) 1.833×1.833×2.5, square steel 135×12mm

Hoisting Mechanism


Speed (m/min) 80/40/8.5 40/20/4.25
Motor power (kw) 30/30

Slewing Mechanism


Speed (r/min) 0.6
Motor power (kw) 2*3.7

Trolleying Mechanism


Speed (m/min) 40/20
Motor power (kw) 3.3/2.2

Jacking-up System


Speed (m/min) 0.4
Motor power (kw) 5.5
Total Power (kw) 46.2
Power Supply 380V/50Hz, 220V/60Hz or others


Main Features
1) This tower crane with a horizontal jib (boom).
2) Four Mechanisms: Hoisting mechanism, Slewing mechanism, trolleying mechanism and hydraulic self-raising mechanism.
3) It is original in design, reliable in operation and satisfactory in shape.
4) Equipped with full set of safety device so that it could shows a good speed-control capacity, satisfactory operating stability and high work efficiency.
5) They can be widely used for the construction of high-rise hotels, residential buildings, high-rise industrial buildings, large-span factory buildings and tower-like buildings.

Pictures
qtz100 60m Hammer-Head Tower Crane For 150m Building Construction 0qtz100 60m Hammer-Head Tower Crane For 150m Building Construction 1
