Product Details:
Payment & Shipping Terms:
|
| Application: | Buildings And Projects | Type: | Fixed With Tower Head |
|---|---|---|---|
| Max. Load: | 10 T | Jib Length: | 60 M |
| Tip. Load: | 2.2 T | Power supply: | 380V/50Hz Or According To Client's Requirements |
| Mast section: | 1.835*1.835*2.5 M Or 2*2*3 M (split Type) | Main Chord: | 125*14mm Or 200*20mm |
QTZ160 Tower Crane without Head PT6022 10tons Faucet 60m Freestanding Height
Description
PT6022 Topless Tower Crane was a topless split tower crane, various performance indicators have reached international levels, the split mast sections all achieve impeller blasting, improve the surface hardness of steel, enhance the coating adhension, extend equipment useful life. Mast sections adopt split structure, convenient for transportation and storage, save the long distance freight, the main chord of mast section adopts Q345B materials, adaptability to environment. The mechanism adopt domestic famous factory products, reliable performance, good governing performance and shocklessness.
Our company employs 300 skillful personnel and is equipped with Panasonic professional robotic welding equipment, machining centers, large CNC gantry milling, CNC double-sided milling, CNC plasma cutting machines, computer-aided assembly line, fully automated spraying line and so on. Therefore, we can easily meet your requirements.
Specification
| Type | Topless or Flattop no head |
| Max. Lifting Load (t) | 10 |
| Tip Load (t) | 2.2 |
| Max. Lifting Height with anchorage (m) | 200 |
| Free standing height (m) | 45-60 |
| Rope length (m) | 400 |
| Span (m) | 60 |
| Working range (m) | 3 to 60 |
| Slewing speed (r/min) | 0-0.6 |
| Trolley peed (m/min) | 0-60 |
| Jacking-up speed (m/min) | 0.4 |
| Power supply | 380V/50Hz or according to client's requirements |
| Power Capacity (KW) | 61.5 |
| Electric switch box | Schneider |
| Hoisting speed (m/min) | (a=2)0-80; (a=4)0-50 |
| Mast section (m) |
1.835*1.835*2.5 (125*14mm two angle steel with rib) Or 2×2×3, angle steel 200×20mm |
FAQ
Q1: Will you help with installation and stuff training?
Yes,we will send engineers to you and guide the installation and train your workers.
Q2: How do you control the quality ?
We insist the "Quality is priority"always pay attention to quality control from the very the beginning to the end .You can also be reassured by our one-year warranty and ISO certificates
Q3:Where is your factory located ?How can i visit there ?
Our factory is located Zhangqiu city, Shandong province, China.
All our clients- from home and abroad are warmly welcome to visit us!
Advantage of Fixed Tower Crane
1. 15 years of experience in supplying new tower cranes.
2. Export to more than 20 countries with CE/ISO/GOST/CU-TR Certificates.
3. Mobile and internal climbing type tower cranes are also available.
4. Impeller blasting and rust protection painting with advanced painting process.
5. Strict and experience welding line
6. New designed mast, can be used to Internal and external climbing tower crane
7. Well known brand mechanism system, Schneider Electronic control system, Jjiangte or Jiuhe motor
8. Engineers available to service machinery overseas.
9. For warranty: 12 months from the B/L date.
Photos
