Product Details:
Payment & Shipping Terms:
|
| Condition: | 100% New | Application: | Buildings And Projects |
|---|---|---|---|
| Type: | SINGLE CAGE | Capacity: | 1 Tons |
| Height: | 120 M | Rated Speed: | 33 M/min Or 0-33m/min |
| Power supply: | 380V/50Hz Or According To Client's Requirements | Motor Power: | 2*11 Kw |
| Motor Brand: | Shuangma, Taichang, Jinnuoi Or Other | Mast Section Size: | 650*650*1508mm |
SC100 Passenger Cum Material Hoist of SINGLE CAGE Capacity 1 Ton and Height 120m
Simple parameter
Model: SC100 Single cage construction hoist
Rated load: 1000kg (1ton)
Raged passengers: 10
Motor power: 2*11kw
Rated lifting speed:33 or 0-33 m/min
Mast section size: 0.65*0.65*1.508m or 0.8*0.8*1.508m
Cage size: 3.2*1.5*2.2m or according to clients needs
Power supply: 380V/50Hz, 220V/60Hz or others
Max. Lifting height: 250m
With all standard accessories
Specification
| Model | SC100 single cage construction hoist |
| Payload capacity | Up to 1000 kg |
| Speed (m/min) | 33 or 0-33 or others |
| Max. lifting height | 150-200 m (Increased lifting height on request.) |
| Cage width (internal) | 1.3 m & 1.5 m |
| Cage length (internal) | 3 m |
| Cage height (internal) | 2.2 m |
| Motor control | Directly driven without inverter |
| Motor power | 2x11 kw |
| Power supply range | 380V, 50Hz or 60 Hz, 3 phase |
| Type of mast | 650mm, Tubular steel with integrated rack |
| Length mast section | 1.508 m |
| Weight mast section with 1 racks | 127 kg |
Parts
1. Driver Cabin
The driver cabin of our construction hoist is constructed from hot dip galvanized plates with surface powder spraying treatment which ensure superior corrosion resistance. It has fan that can improve driver's working environment.
2. Gear Train
The new back gear is lengthened by one time at the stationary bearing end where it is equipped with locating taper pin to improve stress state and avoid loosening of back gear that will affect gear backlash.
The parts such as bear gear, idler wheel, etc. that have influence on running stability are improved to enhance machining and manufacturing precision. All of them will experience thermal refining treatment and galvanizing treatment after that, thus showing excellent durability. Case door pulley and cable pulley are made from nylon material which can prolong their life time and effectively reduce noise.
More products available:
Tower Cranes
---- QTZ Topkit/Hammer Head Tower Cranes: Working jib from 30-75m and max.load from 4-25t.
---- PT Topless/Flat Top Tower Cranes: Working jib from 30-80m and max.load from 4-32t.
---D Luffing Tower Crane: Working jib from 25-60m and max.load from 3-25t.
---QD Derrick Crane: load from 3t to 25t for disassemble inner climbing tower cranes.
SS Building Material Lift / Hoist
------ Wire rope lift, special material lifting work in construction site, 1000kg to 2000kg capacity, no passenger, up to 60m.
ZLP Suspended Platform
SJY Scissor Lift
