Payment & Shipping Terms:
|Condition:||100% New||Application:||Buildings And Projects|
|Type:||Top Slewing||Max. Load:||10 Ton|
|Jib:||215 Ft||Tip Load:||2t|
|Power supply:||380V/50Hz Or According To Client's Requirements||Mast section:||2*2*3 M|
|Electric Box:||Schneider||Power Supply:||380V/50Hz, 415V/50Hz, 220V/50Hz Or According To Clients Need|
10 TON QTZ6520 Topkit Tower Crane 215 ft Jib 2t Tip Load 160 ft Height
1. TC6520 Tower Cranes are ideal for medium-sized and large construction projects, for example in industry and plant construction.
2. This Tower Cranes can handle high load capacities and have an unmistakable silhouette. The various size classes prove their worth for medium and large construction projects, for example for industrial and plant construction.
3. Tower cranes are also suitable for use on very high buildings. Our customers benefit from enormous hoisting heights and hoist speeds.
|Rated Lifting Moment (KN.M)||2300|
|Rated Loading Capacity (t)||10|
|Max. Lifting Load (t)||10|
|Working range (m)||3 to 65|
|Tip Load (t)||2.0|
|Max. Lifting Height (m)||180|
|Free standing height (m)||60|
|Rope length (m)||500|
|Slewing speed (r/min)||0-0.6|
|Trolley peed (m/min)||0-60|
|Jacking-up speed (m/min)||0.4|
|Power supply||380V/50Hz or according to client's requirements|
|Power Capacity (kw)||61.5|
|Electric switch box||Schneider|
|Main Material (mm)||200*20 / angle steel|
|Mast section (m)||2*2*3 (split type)|
1) Lifting multiplying factor switch-over which could achieve high speed for light load and low speed for heavy load.
2) Our tower sections are exchangeable, which provide our customers more conveniences.
3) We adopt to use Dual drawbars structure on lifting boom, which enables the lifting boom to be under no stress at lifting surface other than uniaxial stress, and moreover, it gets rid of the stress peak. It greatly improves the fatigue safety performance of lifting boom.
4) Adopts VVVF stepless speed variation device for lifting, radius changing and slewing mechanisms, to make sure it works steadily and effectively, it also lowers the maintenance cost.
It's lifting height is obviously increased thanks to its self-erecting and wall attached function.
It is applicable for construction of different industrial, commercial, office, and civil building lower than 120m, and becomes an ideal service-building machine at home.
1. Export to more than 20 countries with CE/ ISO/ GOST Certifications by skilled sales team.
2. Mobile and internal climbing type tower cranes are also offering as new designed mast sections.
3. High Quality control: blasting and rust protection painting with advanced painting process. Strict and experience welding line.
4. Well known Mechanisms system and Schneider Electronic control system.
5. Engineers are available to service machinery overseas within 12 months warranty from the B/L date.
6. One set free easy-worn spare parts are provided with per set tower cranes.
1. Are you a manufacturer or a trading company?
We are as a professional manufacturer / factory since 2002 year for 16 years.
2. What is your advantage?
1) We are a manufacturer, so the price is more competitive than the trading company.
2) It is more effective to communicate with the factory, saving more time for you.
3) Timely after sales service
4) We also produce other construction machinery such as construction hoists, derrick cranes and ZLP Suspended Platform to meet your requirements.
3. How do you guarantee your product quality?
We have our professional testing department , and will test the machine all the progress, and will test it after finished and before delivery.
4. I plan to label our logo on your products, is that possible?
Sure it is ok. OEM is available for us. Just send your logo, brand name or picture to us.
5. How about the warranty period ?
The warranty will be one year from the date of shipment. Any detected parts during this period caused by the quality of products will be replaced by seller free of cost (exclude wear and tie parts), improper operation and other man made reasons are excluded.
