Telecrane F24-60 Industrial Joystick Wireless Remote Control For Crane
Desctription:
F24-60 has extraordinary communication design-simultaneous encoding and decoding transmission, interference elimination,error detection and correction, and frequency resettable manually.
F24-60 has large amounts of programmable functions and is extensible using Windows compatible software with free update Functions are all programmable .
Features:
· Up to 40 control contacts.
· With battery voltage warning device, the power supply is cut off during low power.
· Safety switch key is to prevent from unauthorized user.
· Program the button function by computer interface.
· Start key can be programmed to start, toggle switch, normal or other functions.
· The spare buttons can be programmed to start, toggle, interlock or normal, etc Installed with proportional module for analog signal output (optional)
Basic information:
| Control distance |
Up to 100m |
| Control point |
40 |
| Certificates |
CE, FCC, ISO9001 |
| Unique code |
Over 4.3billon unique ID codes . |
| Working temperature |
-35°C___+80°C |
| Enclosure protection class |
IP65 |
| Transmitter power |
DC 6V |
| Receiver power |
AC380v/220V/110v/48v/36v/24vor AC/DC12V |
| Output capacity |
Full sealed relay output with 5 amperes |
| Frequency |
VHF 312-331MHz. |
| Radio output |
0-10v |
| F24-60 Transmitter Parameters |
| Material |
Glass-Fiber PA |
| Enclosure protection class |
IP65 |
| Frequency range |
VHF: 310-331MHz (UHF: 425-446MHz is optional) |
| Transmitter power |
≤10dBm |
| Transmitter power supply |
2 AA alkaline batteries (not included) |
| Safety code |
32 bits (4.3billion) |
| Temperature range |
-40℃-+85℃ |
| Control distance |
Approx 100m(200 meters is customized) |
| Size |
210x152x128mm |
| Weight |
980g (without battery) |
| F24-60 Receiver Parameters |
| Material |
Glass-Fiber PA |
| Enclosure protection class |
IP65 |
| Frequency range |
VHF: 310-331MHz; UHF: 425-446MHz |
| Receiver sensitivity |
-110dBm |
| Receiver power supply |
18~65V AC/DC; 65~440V AC/DC (optional) |
| Safety code |
32 bits (4.3billion) |
| Temperature range |
-40℃-+85℃ |
| Output contactor capacity |
8A sealed relay output (with AC 250V/10A relays, 10A fuse) |
| Cable length |
1.65m (Other length can be customized) |
| Size |
320x253x107mm |
| Weight |
2020g |
Products Application:
F24-60 Dual joystick remote control mainly used on tower crane, overhead cranes, concrete pumps truck
or others condition which are much more complex.
