Product Details
Place of Origin: China
Brand Name: Telecrane
Certification: ISO, CE
Model Number: F24-60
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: $500-1000 per set
Packaging Details: Carton
Delivery Time: 1-5 days after receiving the deposit
Payment Terms: Western Union, L/C, T/T, MoneyGram
Supply Ability: 100000 Piece/Pieces per Year
Condition: |
100% New |
Application: |
Tower Cranes |
Material: |
Plastic And Silicone |
Color: |
Black Orange |
Protection Level: |
IP65 |
Shell Material: |
PA6(30%GF) |
Control Distance: |
100M |
Voltage: |
AC36V, AC220V,AC380V |
Condition: |
100% New |
Application: |
Tower Cranes |
Material: |
Plastic And Silicone |
Color: |
Black Orange |
Protection Level: |
IP65 |
Shell Material: |
PA6(30%GF) |
Control Distance: |
100M |
Voltage: |
AC36V, AC220V,AC380V |
Tower Crane Part Wireless Radio Remote Control System F24-60 Models
Desctription:
F24-60 has extraordinary communication design-simultaneous encoding and decoding transmission, interference elimination,error detection and correction, and frequency resettable manually.
F24-60 has large amounts of programmable functions and is extensible using Windows compatible software with free update Functions are all programmable .
Features:
· Up to 40 control contacts.
· With battery voltage warning device, the power supply is cut off during low power.
· Safety switch key is to prevent from unauthorized user.
· Program the button function by computer interface.
· Start key can be programmed to start, toggle switch, normal or other functions.
· The spare buttons can be programmed to start, toggle, interlock or normal, etc Installed with proportional module for analog signal output (optional)
Basic information:
Control distance |
Up to 100m |
Control point |
40 |
Certificates |
CE, FCC, ISO9001 |
Unique code |
Over 4.3billon unique ID codes . |
Working temperature |
-35°C___+80°C |
Enclosure protection class |
IP65 |
Transmitter power |
DC 6V |
Receiver power |
AC380v/220V/110v/48v/36v/24vor AC/DC12V |
Output capacity |
Full sealed relay output with 5 amperes |
Frequency |
VHF 312-331MHz. |
Radio output |
0-10v |
F24-60 Transmitter Parameters | |
Material | Glass-Fiber PA |
Enclosure protection class | IP65 |
Frequency range | VHF: 310-331MHz (UHF: 425-446MHz is optional) |
Transmitter power | ≤10dBm |
Transmitter power supply | 2 AA alkaline batteries (not included) |
Safety code | 32 bits (4.3billion) |
Temperature range | -40℃-+85℃ |
Control distance | Approx 100m(200 meters is customized) |
Size | 210x152x128mm |
Weight | 980g (without battery) |
F24-60 Receiver Parameters | |
Material | Glass-Fiber PA |
Enclosure protection class | IP65 |
Frequency range | VHF: 310-331MHz; UHF: 425-446MHz |
Receiver sensitivity | -110dBm |
Receiver power supply | 18~65V AC/DC; 65~440V AC/DC (optional) |
Safety code | 32 bits (4.3billion) |
Temperature range | -40℃-+85℃ |
Output contactor capacity | 8A sealed relay output (with AC 250V/10A relays, 10A fuse) |
Cable length | 1.65m (Other length can be customized) |
Size | 320x253x107mm |
Weight | 2020g |
Products Application:
F24-60 Dual joystick remote control mainly used on tower crane, overhead cranes, concrete pumps truck
or others condition which are much more complex.
