Product Details:
Payment & Shipping Terms:
|
| Condition: | 100% New | Application: | Load Passengers To Aerial Work |
|---|---|---|---|
| Type: | Hydraulic Drive | Load: | 320kg |
| Working Height: | 14m | Lifting/Descend Speed: | 85/75 Sec |
| Lifting Motor/Drive Motor: | 48/4 V/kw | Battery: | 2x48/4 KW |
| Platform Material: | High Strength Steel | Platform Size: | 2270x1120 Mm |
| Color: | Orange,blue, Yellow Or Others |
CFPT1214LDS Mobile Hydraulic Crawler Scissor Lift with Outrriger EWX FOB CIF Price
General Introduction of this scissor lifts work platform
1. Load capacity: 320kg
2. Lifting height: 14M
3. Applications: aerial installation, maintenance, clean at the construction sites, workshops, warehouse, hotel, airport, wharf, gas station and stadium etc.
4. Custom-made according to the requirement
5. The worker can control the scissor lift on the platform when raised by handle .
6. The worker can also control the lift on the floor by handle control
Specification of this scissor lifts work platform
| Parameter | Unit | CFPT1214LDS |
| Rated Load Capacity | Kg | 320 |
| Extended platform load | Kg | 113 |
| Max. working height | m | 14 |
| Max. platform height | m | 11.75 |
| Length (L) | mm | 2782 |
| Width (W) | mm | 1581 |
| Height(guardrail unfolded) | mm | 2670 |
| Height(guardrail folded) | mm | 2130 |
| Platform size | mm | 2270x1120 |
| Platform extended | mm | 900 |
| Lifting motor/Drive motor | V/Kw | 48/4 |
| Travel speed(Lower) | Km/h | 2.4 |
| Lifting/Descend speed | sec | 85/75 |
| Battery | V/Ah | 8x6/200 |
| Charger | V/A | 48/25 |
| Grade ability | % | 30 |
| Max. working inclination | . | 1.5/ 3 |
| Overall weight | Kg | 3480 |
Standard equipment of this scissor lifts work platform
Proportional controls
Self-lock gate on platform
Extension Platform
2WD
Automatic brakes system
Emergency lowering system
Emergency stop button
Tubing explosion-proof system
Onboard diagnostic system
Tilt sensor with alarm
All Motion Alarm
Horn
Safety brackets
Forklift pockets
Charger protection
Flashing beacon
Folding guardrails
Product Description
As the ideal model for flexible operation in narrow space, hydraulic electric slab scissor lifts feature nice appearances, compact structures, stability, reliability, strong power performance and field adaptability, flexible operation, excellent quality and safety.
Scissor Lifts cover 8m to 16m work height, hydraulic powered, electric motor drive, which have long run time, and high productivity. The energy•efficient direct electric drive boosts your productivity with industry•leading duty cycles. It is safe and reliable,so it is the optimal product for aerial lifting operation, such as aerial cleaning, repairing, and maintenance.
Self-propelled Scissor Lifts are energy-saving and environmentally-friendly with less noise and no emission. With proportional controls for lift and drive functions, the slab scissor lift boasts the versatility to work in indoor and outdoor construction, maintenance and installation applications with firm, level surfaces.
Features
---Vertical raising of platform
---Convenient and quite operation (can be controlled both on the platform and the ground)
--- Compact Structure
---Horizontal extension of bucket
_ Drivable at full height
-24 V DC battery, flexible and maneuverable
- Full self propelled function, robust, reliable and easy to maintain
Scissor lifts are available in various electric and battery and diesel powered models.
Service
1. All the machines will be full tested before shipment
2. The total machine guarantee is 12 moths
3. 24 Hours technical support, email, telephone or video online
4. User-friendly english manual for machine using and maintaining
5. Sereral sets wearing parts will be free for you
