Product Details:
Payment & Shipping Terms:
|
| Condition: | 100% New | Application: | Load Passengers To Aerial Work |
|---|---|---|---|
| Type: | Hydraulic Drive | Load: | 320kg |
| Working Height: | 14m | Lifting/Descend Speed: | 60/50 Sec |
| Lifting Motor/Drive Motor: | 24/4.5 V/kw | Battery: | 4x12/300 V/Ah |
| Platform Material: | High Strength Steel | Platform Size: | 2270x1120 Mm |
| Color: | Orange,blue, Yellow Or Others |
300kg 12m Platform Height Hydraulic Scissor Lift Mobile Skyjack Platform
General Introduction of this scissor lifts work platform
1. Load capacity: 320kg
2. Lifting height: 13.8m
3. Applications: aerial installation, maintenance, clean at the construction sites, workshops, warehouse, hotel, airport, wharf, gas station and stadium etc.
4. Custom-made according to the requirement
5. The worker can control the scissor lift on the platform when raised by handle .
6. The worker can also control the lift on the floor by handle control
Specification of this scissor lifts work platform
| Parameter | Unit | CFPT1214 |
| Rated Load Capacity | Kg | 320 |
| Extended platform load | Kg | 113 |
| Max. working height | m | 13.8 |
| Max. platform height | m | 11.8 |
| Length (L) | mm | 2480 |
| Width (W) | mm | 1190 |
| Height(guardrail unfolded) | mm | 2570 |
| Height(guardrail folded) | mm | 2030 |
| Platform size | mm | 2270x1120 |
| Platform extended | mm | 900 |
| Ground clearance (Lower) | mm | 100 |
| Ground clearance (Raised) | mm | 19 |
| Wheel base | mm | 1895 |
|
Min. Turning radius (inner wheels) |
mm | 0 |
|
Min. Turning radius (outer wheels) |
mm | 2200 |
| Lifting motor/Drive motor | V/Kw | 24/4.5 |
| Travel speed(Lower) | Km/h | 3.5 |
| Travel speed(Raised) | Km/h | 0.8 |
| Lifting/Descend speed | sec | 60/50 |
| Battery | V/Ah | 4x12/30 |
| Charger | V/A | 24/25 |
| Grade ability | % | 25 |
| Max. working inclination | . | 1.5/ 3 |
| Tyre size | mm | Φ381x127 |
| Overall weight | Kg | 2980 |
Standard equipment of this scissor lifts work platform
Proportional controls
Self-lock gate on platform
Extension Platform
Drivable at full height
Non marking tyre
2WD
Automatic brakes system
Emergency lowering system
Emergency stop button
Tubing explosion-proof system
Onboard diagnostic system
Tilt sensor with alarm
All Motion Alarm
Horn
Hour meter
Safety brackets
Forklift pockets
Charger protection
Flashing beacon
Folding guardrails
Automatic pothole protection
Product Description
As the ideal model for flexible operation in narrow space, hydraulic electric slab scissor lifts feature nice appearances, compact structures, stability, reliability, strong power performance and field adaptability, flexible operation, excellent quality and safety.
Scissor Lifts cover 8m to 16m work height, hydraulic powered, electric motor drive, which have long run time, and high productivity. The energy•efficient direct electric drive boosts your productivity with industry•leading duty cycles. It is safe and reliable,so it is the optimal product for aerial lifting operation, such as aerial cleaning, repairing, and maintenance.
Self-propelled Scissor Lifts are energy-saving and environmentally-friendly with less noise and no emission. With proportional controls for lift and drive functions, the CFMG slab scissor lift boasts the versatility to work in indoor and outdoor construction, maintenance and installation applications with firm, level surfaces.
Service
1. All the machines will be full tested before shipment
2. The total machine guarantee is 12 moths
3. 24 Hours technical support, email, telephone or video online
4. User-friendly english manual for machine using and maintaining
5. Sereral sets wearing parts will be free for you
More products available:
Tower Cranes
---- QTZ Topkit/Hammer Head Tower Cranes: Working jib from 30-75m and max.load from 4-25t.
---- PT Topless/Flat Top Tower Cranes: Working jib from 30-80m and max.load from 4-32t.
---D Luffing Tower Crane: Working jib from 25-60m and max.load from 3-25t.
---QD Derrick Crane: load from 3t to 25t for disassemble inner climbing tower cranes.
SC Construction Man and Material Elevator
------ Rack and pinion elevator, special for the lifting work of construction Man and Material, 1000kg to 4000kg capacity, Passenger and Material, up to 200m. .
SS Building Material Lift / Hoist
------ Wire rope lift, special material lifting work in construction site, 1000kg to 2000kg capacity, no passenger, up to 60m.
ZLP Suspended Platform
---Most popular model ZLP630, ZLP800: 630KG AND 800KG
