High Quality 15m Boom HGY15 Concrete Place Boom Hydraulic Type
Performance parameters
Мах. boom length - 15 m;
Concrete pipe line (steel, DN125 mm), outer diameter of the and fitting on pipes - 148 mm;
The High pressure flexible concrete hose with two and fitting (3000 mm) must be included in the delivery;
Support - outrigger (4 legs);
Remote control - wired remote control.
Specification
| Mobile Hydraulic Concrete Placing Boom |
| |
Project name |
HGY13 |
HGY15 |
HGY17 |
HGY19 |
HGY21 |
HGY23 |
| |
Max. working radius |
13m |
15m |
17m |
19m |
21m |
23m |
| |
Tilt working range |
0°~84° |
0°~89° |
0°~84° |
0°~84° |
0°~84° |
-4°~90° |
| |
Slewing working range |
Full Rotary |
| |
Motor power of hydraulic washing system |
4kw |
4kw |
5.5kw |
7.5kw |
22kw |
22kw |
| |
Working pressure of hydraulic system |
20mpa |
20mpa |
20mpa |
20mpa |
32mpa |
32mpa |
| |
Slewing speed |
0.46r/min |
0.2-0.3/min |
0.2-0.3/min |
0.2-0.3/min |
0.2-0.3/min |
0.2-0.3/min |
| |
Concrete pipe specification |
∅125*4 |
| |
Length of hose at arm end |
3m |
| |
Outrigger span |
4000*4000mm |
4231*4231mm |
5167*5167mm |
| |
Overall size of the machine |
8900*4000*2585 |
6000*5000*4000 |
6670*5730*4510 |
6500*4800*4600*5312 |
6839*5089
*5060*5800 |
| |
Slewing angle |
360° |
360° |
360° |
360° |
360° |
360° |
| |
Weight (self-weight/counterweight T) |
2.7/4.3 |
3.23/5.43 |
5/7.2 |
5.3/7.5 |
7.7/9.9 |
8/10.2 |
Our Skilled Team
Our R&D team is made up of the most prestigious, experienced engineers and experts in this field. Our technicians team are all experienced senior mechanicians.
We provide satisfactory service (pre-sale, while-sale, after-sale).
Our professional advice and instruction are always available and acceptable.
FEATURES
1. One button stabilization technology
The press of a button brings the boom to a smooth and immediate stop.
2. Smart boom system
Advanced technology to increase overall efficiency and reduce operator fatigue.
3. Boom anti-vibration technology
Minimizes chatter during pumping, to allow steady delivery.
4. Swing control technology
Rotary braking delivers precise swing operations.
5. Highly wear-resistant parts
Improved service life and reduced operating costs.
6. Protection technology
Features such as boom overload protection and hydraulic oil level monitoring are used to prevent damage.
7. Energy-saving technology
Increased pumping efficiency equals reduced fuel consumption.
A. Pre-sales service:
1. Selecting the most suitable equipment,
2. Designing your personal machinery according to special construction demands,
3. Training your technicians to operate our equipment,
4. Providing advice to ensure equipment running well in various construction. environments,
5. Making new construction scheme if necessary.
B. Sales service:
1. Equipment delivery transport agent,
2. Equipment quality control before delivery,
3. Introduce our service system to customers.
C. After-sales service:
1. Making the first construction scheme,
2. Installing and debugging your equipment,
3. Troubleshooting on site, prompt and initiative,
4. door to door accessories and parts,
5. Opportunities to get technical communications with our engineers.
D. Value-added service:
1. Overall process and zero distance technology tracking service for key projects,
2. Carry out large maintenance business,
3. Regular equipment checking service,
4. Technology update,
4. Provide professional periodic maintenance standards for customers.
Photos
