Payment & Shipping Terms:
|Condition:||100% New||Application:||Buildings And Projects|
|Type:||Electric Cable Climbing||Max. Load:||1-4 T|
|Max. Height:||150-200 M||Rated Speed:||34.4 Or 0-36 M/min|
|Power supply:||380V/50Hz Or According To Client's Requirements||Motor Power:||2*11kw Or 2*3*11 Kw|
|Motor Brand:||Xingxiang, Sanshang, Juli Or Other||Mast Section Size:||650*650*1508 Mm|
SC Models Building Construction Hoist Elevator 500kg to 6000kg load capacity
1. Adopting rope protection device; the jam boards on both sides of the cage would lock the cage and prevent it from crash once the rope breaks.
2. Stop device is available on request for floor parking.
3. Adopting separate lifting navigation to avoid direct friction between wheels and basket body, thus prolongs the service time.
4. Adopting Overload Limiter to avoid overload accidents.
5. Equipped with a bi-way travel limiter supporting the use of winch, which can efficiently prevent punch and crash accidents.
6. The hanging basket is completely closed with protection screen and floor to prevent material slide and guarantees the personnel.
|Classification||Model||Rated Load(kg)||Speed(m/min)||Motor Power(KW)|
Normal Construction Elevator
Frequency Construction Elevator
|SC200||2000||0-40 or 0-60||2×11|
|SC100||1000||0-40 or 0-60||2×11|
|SC100/100||2×1000||0-40 or 0-60||(2×2)×11|
|SC200/200||2×2000||0-40 or 0-60||(2×3)×11|
1. Newly designed height of the cage (2.46m), which can save freight.
2. Top of the cage is made of a complete high-grade steel, so the waterproof performance is greatly improved.
3. Body of cage is made of mesh steel plate, appearance of which with special spray technology which makes cage more beautiful, can completely against rust and prolong its usage life-span.
4. Door frame is made by light weight steel shape which can make cage more stable.
5. Special embedded counterweight design. More safe and stable in.
6. Improved door handle makes the operation more easily.
