Payment & Shipping Terms:
|Condition:||100% New||Application:||Buildings And Projects|
|Type:||Fixed With Small Lifting Bar||Capacity:||4 Ton|
|Luffing Jib:||30mts||Tip Load:||1.5tons|
|Power supply:||380V/50Hz Or According To Client's Requirements||After Sale Service:||Engineers Available To Service Overseas|
|Color:||Yellow Or According To Clients Need|
D3015 Derrick Tower Crane 30mts Luffing Jib 1.5tons Tip Load FOB Price
1. The Derrick cranes is fixed to the roof.
2. The base is then attached to the slewing unit that allows the crane to sewing.
3. On top of the slewing unit there are two main parts which are: the long jib, shorter counter-jib,
4. The long jib is the part of the crane that carries the load.
5. The crane operator either sits in a cab at the top of the tower or controls the crane by radio remote control from the ground.
6. The lifting hook is operated by the crane operator using electric motors to manipulate wire rope cables through a system of sheaves.
|QD3015 Derrick Crane Specification|
|Rated Lifting Moment||600KN.m|
|Rated Loading Capacity||4t|
|Max. Lifting Load||4t|
|Max. Lifting Height||200m|
|Jib length / Span||30m|
|Working range||3 to 30m|
|Trolleying speed||0-10 m/min|
|Luffing speed||A4=32/16/3.5 m/min|
|Power supply||380V/50Hz or others|
|Electric switch box||Schneider|
|Slewing bearing model||1220.32|
Advantages of Derrick Crane
·Operations at great heights
·Adaptable universal machine for heavy loads
·Adaptable support base
·Compact component dimensions
·Maximum weight of individual transportation units
Service of of Derrick Crane
a. Rapid response to any inquiries and 24 hours on-line service.
b. Competitive price which directly from facotry. Welcome to visit us.
c. Professional inspection department to guarantee quality.
d. Engineers will go to construction site for guiding the installation and test-running for first time if clients needs.
e. 12 months super long time guarantee warranty.
1. Are you a manufacturer or a trading company?
We are as a professional manufacturer / factory since 2002 year for 15 years.
2. What is your advantage?
1) We are a manufacturer, so the price is more competitive than the trading company.
2) It is more effective to communicate with the factory, saving more time for you.
3) Timely after sales service
4) We also produce other construction machinery such as construction hoists, derrick cranes and ZLP Suspended Platform to meet your requirements.
3. How do you guarantee your product quality?
We have our professional testing department , and will test the machine all the progress, and will test it after finished and before delivery.
4. I plan to label our logo on your products, is that possible?
Sure it is ok. OEM is available for us. Just send your logo, brand name or picture to us.
5. How about the warranty period ?
The warranty will be one year from the date of shipment. Any detected parts during this period caused by the quality of products will be replaced by seller free of cost (exclude wear and tie parts), improper operation and other man made reasons are excluded.
Photo of of Derrick Crane
