1TONS SS100 Material Elevator Building Hoist 24m to 60m Height 380V 60Hz
Introduction
SS100 Material Elevator is a product introduced in accordance with GB/T10054-2005 "Construction Elevator" research and development, widely used in the vertical transport of high-rise and multi-storey construction, mining, workshop materials. The utility model has the advantages of simple structure, quick and easy installation and disassemble, safe and reliable use, economic benefits and high work efficiency.
Specification
| No. | Item | Unit | Value |
| 1 | Height | Freestanding | m | 24 |
| Max. height | m | 60 |
| 2 | Mast section size | m×m×m | 0.8×0.8×1.508 |
| 3 | Cage size | m×m×m | 3×1.3×1.9 |
| 4 | Rated load | kg | 1000 |
| 5 | Rated speed | m/min | 22 |
| 6 | Motor | Y132M-4-5.5KW |
| 7 | Brake | MZD-- 200 |
| 8 | Wire rope | 6*19-11-1750-1 |
| 9 | Working condition | -20℃+40℃ |
Distinctive Features
1. Safety protection device is complete and reliable. For safety device with national patent technology, make the machine working reliability among the top of the same products.
2. Modular design, through different collocation, different speed, different lifting weight can be combined from the elevator specifications. The product standard, practicability and generalization are greatly improved.
3. Smooth operation and comfort. Because the machine will be top drive unit in the cage, cage net space increases; At the same time also make driving more smoothly, mechanical vibration, brings to the operation staff a comfortable and spacious environment.
Use this machine is a wise choice, you set the construction lifter can become your modernization construction's right-hand man, for your construction efficiency.
Safety device
1. Overweight protection
2. Phase sequence protection
3. Safety door protection
4. Interlayer protection
5. Motor reverse protection
6. Mechanical anti-roll top protection
7. Sensor failure protection
8. Motor short circuit or overload protection
9. Bell output function
10.Data protection
